MODEL P2280 EQ (PZA)
High-power 12-channel multi-zone amplifier with equalizer.
The Architect "P" Series excellently complements AudioControl's popular Architect series of high-power multi-zone amplifiers, delivering 100 watts RMS per channel into 8 ohms and 200 watts per channel into 4 ohms, all channels driven.
The compact 2U chassis offers 12 channels of high-power amplification, and the Architect P2280 EQ delivers 100 watts per channel into 8 ohms and 200 watts per channel into 4 ohms, all channels driven. Channel bridging increases power to a remarkable 400 watts into 8 ohms. Benefitting from 35 years of AudioControl’s patented cool-running amplifier design, the Architect P2280 EQ is equipped with features such as input bus, output pass-through, global 12VDC trigger input/output with local 12VDC trigger inputs for all zones, and input signal sensing on/off. The A-bus includes a coaxial S/PDIF input for a digital source. Amplifier channels and connected speakers are protected by AudioControl’s fast-acting LightDrive anti-clipping circuitry. AudioControl's legendary EQ controls are easily accessible from the front panel and can be covered with an included magnetic security panel once the system is set up.
12 channels of AudioControl power and performance
100 watts per channel into 8 ohms (all channels driven)
200 watts per channel at 4 ohms (all channels driven)
Configurable in 6 bridged channels
400 watts bridged channel power at 8 ohms
Low-power cool running
Low power consumption in standby mode, 1 watt or less
Compact design fits in 2 rack spaces
LightDrive anti-saturation protection circuit
2 bus inputs A (digital) and B (analog)
12 VDC Global Trigger Input and Output
Remote/Local Zone Input Trigger
Signal detection on all channels
Level controls for all input pairs
Stereo to mono switch for easy channel bridging
Rack mounting brackets included
