HPA2408

HPA2408

by ATLAS SOUND
Sold out
$ 115,457.58
MEASURES
COLOR: N/A

Amplifier (PZA)

Eight-channel, 2400-watt commercial amplifier

The AtlasIED “HPA” series high-power amplifier is designed for use in commercial 25V/70V/100V distributed systems or low-impedance 8 or 4 ohm applications requiring amplifiers to drive multiple impedance loads. The HPA2408 is compact and lightweight compared to other models offering similar performance. The HPA2408 features a Generation II Class D output topology that provides high-efficiency amplification with the sound quality of a Class AB amplifier. The power supply is designed for global use and features a wide-range voltage power supply with power factor correction and remains stable during fluctuating power conditions. The combination
The PFC power supply and highly efficient output stage collectively deliver exceptional, dynamic output voltage and current to virtually any speaker load without requiring a huge amount of AC power.

The HPA Series features stepped, front-panel level controls with safety covers, remote power-on, balanced line inputs with sensitivity settings, fault reporting, and accessory card slots for an optional eight-channel Dante™ digital audio interface. Cooling is not an issue due to the output stage's unique low-resistance direct-couple thermal transfer design. HPA is also energy efficient and meets Energy Star 1W standby standards.

Whether the application is a large constant-voltage distributed sound system or a high-SPL sound reinforcement system, the AtlasIED HPA Series is the answer to your reliable, cost-effective, high-power amplification needs.

CHARACTERISTICS:

  • 4Ω, 8Ω, 25V, 70V and 100V operation
  • The load of each channel can be independent of the others.
  • Requires only a 15A AC power supply for 120V operation.
  • Remote start
  • Accessory card slots for optional Dante™ digital network audio cards
  • Bug report
  • Dimmers retained with safety covers.
  • Stereo or parallel operating modes
  • Selectable input sensitivity
  • BUSS input with individual channel assignments
  • Multi-stage fan cooling
  • Removable air filters
  • Wide-range AC mains power supply 100 V - 240 V with PFC
  • Meets Energy Star standards for 1W standby mode
